HOLE PUNCHERS

76000PR 18V Cordless Hole Puncher

Part No: 0760102

The 76000PR is the smallest and most lightweight model in the Hougen-Ogura hole puncher lineup, delivering powerful punching performance in a highly portable package. Powered by an 18V battery, the 76000PR can quickly punch round and oblong holes through material up to 1/4″ (6.4 mm) thick, making it ideal for a wide variety of fabrication and installation applications.

Weighing just 17.4 lbs. (7.9 kg), the compact design is easy to carry and maneuver, allowing operators to work efficiently in tight spaces or at remote job sites. The integrated jog down feature makes it easy to confirm hole location before punching, ensuring accurate hole placement. After each punching cycle, the punch automatically returns to the starting position for increased productivity and ease of operation.

Includes: Carry case, battery, battery charger, 15/32″ (12 mm) punch (76567), die (76587), and tool kit.

Punch Round & Oblong Holes in These Materials

Hougen-Ogura Punches are designed for mild & structural steel, but can be used in other materials. Using in stainless or other materials significantly reduces the capacity. Consult Hougen Technical Support for questions about your particular application: (810) 635-7111

PRESSURE (TONS)11
APPROX PUNCHING SPEED4.5 secs
MAX HOLE SIZE - ROUND19/32" - (15mm)
MAX HOLE THICKNESS - ROUND1/4" - (6.35mm)
MAX HOLE SIZE - OBLONG7/16" x 5/8" (11mm x 15.9mm)
MAX HOLE THICKNESS - OBLONG1/4" - (6.35mm)
MAX THROAT DEPTH.98" - (25mm)
WEIGHT17.42 lbs - (7.9 kg)
SHIPPING WEIGHT34.8 lbs - (15.8 kg)

-ABCDEFGHIJ
76000PR.28.98.511.771.541.571.421.421.8215.39

Measurements in inches

Videos

TIME SAVINGS

Hole Punching is Quicker Than Drilling

FASTER CYCLE TIMES

Be More Productive with Punching

EASE OF HANDLING

Lightweight Single Body Construction

ACCURACY

Precise Holes Exactly Where You Need Them
